Product Parameters
Contact Arrangement： | SPST-NO | ||
Auxiliary Contact： | SPST-NO,≤100mΩ | ||
Voltage Rating： | 12-1500Vdc | ||
Current Rating： | 100A | ||
Coil Voltage： | 12V dc | 24V dc | 48V dc |
Coil Power ： | ≈5.5W | ≈6.0W | ≈5.9W |
Main Contact Mounting： | M5 Internal thread | ||
Dimensions： | 53.8×40.2×58.5mm | ||
Weight ： | ≈160g | ||
Operating Temperature : | -40～+85℃ | ||
Altitude： | ≤4000m | ||
