Product Parameters
Contact Arrangement： | SPST-NO | ||
Auxiliary Contact： | SPST-NO（optional）,≤100mΩ | ||
Voltage Rating： | 12-1500Vdc | ||
Current Rating： | 150A | ||
Coil Voltage： | 12V dc | 24V dc | 48V dc |
Coil Power ： | ≈5.76W | ≈5.76W | ≈5.76W |
Main Contact Mounting： | M8 External thread | ||
Dimensions： | 80.5×66.6×73.8mm | ||
Weight ： | ≈430g | ||
Operating Temperature : | -40～+85℃ | ||
Altitude： | ≤4000m | ||
