Product Parameters
Contact Arrangement： | SPST-NO | |
Auxiliary Contact： | × | |
Voltage Rating： | 12-1500Vdc | |
Current Rating： | 50A | |
Coil Voltage： | 12V dc | 24V dc |
Coil Power ： | ≈3.6W | ≈3.8W |
Main Contact Mounting： | M4 Internal thread | |
Dimensions： | 51.6×35.6×46.2mm | |
Weight ： | ≈115g | |
Operating Temperature: | -40～+85℃ | |
Altitude： | ≤4000m | |
